Routing Sanity: Validation and Testing for LLM Router Configurations

The Problem

LLM router configurations are written once and trusted forever but nobody verifies that math questions actually reach the math-strong model or that cheap queries aren't silently getting routed to GPT-4.

NEO built Routing Sanity to run a structured test suite against any LLM router and produce a routing audit report showing exactly where the configuration breaks down.

The Test Prompt Suite

Routing Sanity ships with 200+ hand-labeled test prompts across six routing categories: math, code, simple, complex, creative, and factual. Each prompt has an expected routing target defined as a model capability class rather than a specific model name this keeps the test suite portable across different provider configurations.

The test manifest is a YAML file that maps prompts to expected routing outcomes:

test_cases:
  - id: math_001
    prompt: "What is the eigenvalue decomposition of a 3x3 symmetric matrix?"
    expected_capability: math_strong
    expected_tier: capable
  - id: simple_003
    prompt: "What is the capital of France?"
    expected_capability: general
    expected_tier: cheap
  - id: code_017
    prompt: "Write a Rust implementation of a lock-free queue using atomics."
    expected_capability: code_strong
    expected_tier: capable

The runner sends each prompt through the configured router and intercepts the routing decision before the LLM call completes (using a mock completion layer), so the test suite runs in seconds without incurring full inference costs.

Routing Validation Engine

The validation engine compares the router's actual routing decision against the expected capability class and tier. It supports four router integration modes: LiteLLM router configs, RouteLLM configurations, custom HTTP routers via a webhook spec, and OpenRouter model selection via API logging.

For each test case, the engine records the routed model, the capability class of that model (looked up from a configurable model registry), whether it matches the expected class, and the latency of the routing decision itself:

python routing_sanity.py \
  --router litellm \
  --config ./router_config.yaml \
  --test_suite ./suites/standard_200.yaml \
  --model_registry ./registries/openai_anthropic.yaml \
  --output report.html

Misrouting examples are extracted and grouped by failure type: wrong_capability (math question routed to a general model), wrong_tier (simple question hitting a capable/expensive model), and routing_failure (the router returned an error or timeout).

Routing Audit Report

The audit report leads with a top-level routing accuracy score broken down by category:

Below the summary, each misrouted test case is listed with the prompt, the expected model class, the actual routed model, and a suggested fix. The fix suggestions are rule-based: if a math prompt routes to a general model, the report recommends adding a keyword-based routing rule for math terminology or adjusting the classifier's confidence threshold.

The report also flags tier leakage simple queries routing to expensive models and estimates the monthly cost impact based on configurable token volume assumptions.

How to Build This with NEO

Open NEO in VS Code or Cursor and describe what you want to build. A good starting prompt for this project:

"Build an LLM router testing suite that loads 200+ categorized test prompts from a YAML manifest, sends each through a LiteLLM or custom router configuration using a mock completion layer, compares routing decisions against expected capability classes and cost tiers, and generates an HTML audit report with per-category accuracy scores, misrouting examples, and cost impact estimates."

Build with NEO →

NEO generates the project structure and core implementation. From there you iterate ask it to add a CI mode that fails the build if routing accuracy drops below a threshold, extend the test suite with domain-specific prompts for your use case, or build a live monitoring mode that samples production traffic and flags routing drift over time. Each request builds on what's already there.

To run the finished project:

git clone https://github.com/dakshjain-1616/routing-sanity
cd routing-sanity
pip install -r requirements.txt
python routing_sanity.py \
  --router litellm \
  --config ./examples/router_config.yaml \
  --test_suite ./suites/standard_200.yaml

Open report.html to see your routing accuracy breakdown, misrouting examples, and estimated cost leakage from tier violations.

NEO built a structured test harness that validates LLM router configurations against 200+ categorized prompts and surfaces misrouting patterns with actionable fix suggestions. See what else NEO ships at heyneo.com.
